Winspace T1600 105 Di2

The Winspace T1600 105 Di2 is a high-performance aero road bike designed for uncompromising speed, stiffness, and control. It excels on flat to rolling terrain, sprints, and in crosswinds.

Advanced Frame Engineering

• Material: Crafted with an advanced carbon layup (Toray T1000 + T1100 + M-Series high-modulus with Kevlar reinforcement), the frame weighs approximately 900 g (size M, unpainted).
• Aerodynamics: Features wind-tunnel-proven aero shaping, offering 5.5 W savings at 48 km/h over 100 km.
• Design Details: Includes a D-shaped airflow intake, jet-inspired head tube, and razor-thin profile for reduced drag and efficient power transfer.

Powerful Shimano 105 Di2 Groupset

• Wireless Shifting: Equipped with the Shimano 105 Di2 R7170 2×12 electronic groupset, delivering seamless wireless shifting.
• Braking: Hydraulic disc brakes ensure precise and reliable braking performance.
• Drivetrain: Features a 50/34T crankset and an 11-34T cassette for versatile gearing.

Integrated Components for Speed and Style

• Cockpit: Integrated HYPER one-piece carbon handlebar and stem (available in 380/400/420 mm handlebar options and 85–125 mm stem options).
• Wheels and Tires: Lún HYPER 3 D45 carbon wheelset paired with Michelin Power Cup or Continental Grand Prix 700×28C tires for fast rolling speed and excellent grip.
• Seatpost: Aero seatpost enhances the sleek design.

Additional Features

• Internal Routing: Fully internal cable routing for clean lines and reduced drag.
• Bottom Bracket: T47-85.5 threaded BB for reliability and ease of maintenance.
• Weight: Complete bike weighs approximately 7.2 kg (size M, without pedals).

Easy Assembly

• Ships 90% assembled. Simply attach the handlebar, seatpost/saddle, front wheel, and pedals. Tools are included for convenience.

Specifications

• Frame/Fork: Toray T1000/T1100/M-Series carbon + Kevlar; T47-85.5 BB.
• Groupset: Shimano 105 Di2 R7170 2×12 (hydraulic disc, 50/34T crank, 11-34T cassette).
• Wheels/Tires: Lún HYPER 3 D45 carbon; Michelin Power Cup / Continental GP 700×28C.
• Cockpit: HYPER one-piece carbon handlebar/stem; Selle Italia SLR Boost Superflow saddle.
• Features: Aero-optimized (wind tunnel validated), ultra-light (~900 g frame), internal routing.
• Intended Use: Aero road racing, fast group rides, competitive events.

Available Sizes

Available in sizes XS–XXL to suit a wide range of riders.

Aero dominance at an unbeatable value – light, stiff, and built for speed!
