Jamis Renegade S3

FULL RANGE

The Renegade is ready for any adventure, no matter which Renegade you ride. The long and tall endurance geometry is designed specifically to ride comfortably all day on the road or in harsh conditions off-road. The smooth ride of the full carbon fiber Renegades set the bar for how we designed the steel and aluminum bikes. With disc brakes and the ability to mount up to a 47c tire, these bikes are ready to go just about anywhere. All you need is the desire to push, pedal and explore. With a full range of sizes from 44 with 650 wheels to 61cm there’s always a Renegade designed just for you.

FRAME

UPDATED Jamis Size Specific Design frame geometry, SST Reynolds 520 double-butted chromoly main tubes, tapered head tube for tapered fork, threaded BB shell, 12mm Thru- axle, flat mount chain stay disc brake mounts, down tube mounted full cable housing, internal dropper post ready, 3 waterbottle mounts, TT mounts, rack and fender eyelets.

FORK

UPDATED Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5” hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and 3 water bottle eyelets

HEADSET FSA OrbitC-40B Internal, 1.5 – 1 1/8”

WHEELS WTB ST i23 TCS 2.0 (UST Tubeless Compliant System) disc rims, 32H, Joytec alloy 6-bolt hubs, 14g stainless steel spokes and front 12mm/rear 12×142 thru-axle with Switch Lever

TIRES WTB Riddler Comp 700CX37C, 30tpi Casing, Wire Bead (48-61) WTB BYWAY 650CX40C, 30tpi Casing, Wire Bead (44)

DERAILLEURS Shimano GRX RD-RX400 Shadow Plus rear and GRX FD- RX400 front with 28.6mm alloy clamp

SHIFT LEVERS Shimano GRX ST-RX400 Dual Control STI, 10-speed

CHAIN KMC 10-speed X10

CASSETTE Shimano 10-speed, 11-36T

CRANKSET FSA OMEGA Modular DM MegaExo, 46/30T, 165mm (44/48), 170mm (51) 172.5mm (54/56) 175mm (58/61)

BB SET FSA BB-4000 MegaExo

BRAKESET Shimano GRX BR-RX400 flat mount hydraulic disc brakes with resin pads, Shimano 160mm rotors with GRX ST- RX400 Dual Control STI levers

HANDLEBAR Ritchey Baquiano Comp, 6061 aluminum, 73 reach, 118 ergonomic drop with 12ç flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)

STEM Ritchey 4-Axis 3D forged 6061 alloy, 6 ̊ x 60mm (44), 70mm (48/51), 80mm (54/56), 100mm (58/61)

GRIPS Jamis suede tape with gel inserts

SEAT POST Ritchey Road, 27.2 x 300mm with cromo seat pin

SADDLE Selle Royal Asphalt with integrated clip system
